Rivetnuts
Open Ended, Flat Head, Round
Rivetnuts
Open Ended, Countersunk, Round
Rivetnuts
Open Ended, Low Profile, Round
Theses are available in a Steel and Stainless Steel Select the button below with your choice and get the PDF data sheet
listing all the options for that part.
W= Body Diameter
H = Head Diameter
L = Length
HT = Head Thickness
T = Thread Size
Rivetnuts
Open Ended, Low Profile, Knurled, Round
Theses are available in a Steel and Stainless Steel Select the button below with your choice and get the PDF data sheet
listing all the options for that part.
H = Head Diameter
L = Length
T = Thread Size
W = Width
HT = Head Thickness
Rivetnuts
Closed End, Flat Head, Round
Theses are available in a Steel and Stainless Steel Select the button below with your choice and get the PDF data sheet
listing all the options for that part.
W= Body Diameter
H = Head Diameter
L = Length
HT = Head Thickness
T = Thread Size
Rivetnuts
Open Ended, Flat Head, Knurled
Theses are available in a Steel and Stainless Steel Select the button below with your choice
and get the PDF data sheet
listing all the options for that part.
W= Body Diameter
H = Head Diameter
L = Length
HT = Head Thickness
T = Thread Size
Rivets
Dome Head, Countersunk and Flat Head
Countersunk, Dome Head and Flat Head are shown here, the theory of measurement is the same.
Some data sheets are available below, select the option you wish to see.
A PDF data sheet is available to download.
L = Length
W = Width
D = Head Depth
HD = Head Width
Brass Thread Inserts For Plastic
Press In Expansion
Brass Insert with flat head.
Open at the bottom allowing the insert to spread out and form in the plastic as the screw goes through the insert.
Select the option below.
A PDF data sheet is available to download.
Brsss Thread Inserts For Plastic
Press In Expansion
Brass Insert with flat head.
Closed at the bottom allowing the insert to spread out from the top and form in the plastic as the screw goes through the insert.
Select the option below.
A PDF data sheet is available to download.
Brass Thread Inserts For Plastic
Press In Expansion
Brass Insert no head.
No head allowing the insert to be flush with the material.
Open at the bottom allowing the insert to spread out and form in the plastic as the screw goes through the insert.
Select the option below.
A PDF data sheet is available to download.
Self Clinching Blind Nuts
Round, Self Clinching, Closed End
Self Clinching Blind Nut, with closed end.
Available in Steel and Stainless Steel.
Select the option you wish and the PDF data sheet is available below
A = Shank
H = Length
C = Width
E = Thread Length
L = Body Length
B = Hole Size
D = Head Width
Rivet Bush
Round, Self Clinching
Rivet Bush.
Available in Steel and Stainless Steel.
Select the option you wish and the PDF data sheet is available below
S = Shank
C = Shank Width
D = Body Length
W = Head Width
Self Clinching Nuts
Round and Hexagon
Available in Steel, Stainless Steel,
Hardened Stainless Steel A4 or Aluminium
A PDF data sheet available for download
listing the parts available
D = Height
Z = Grip Range
T = Thread Size
H = Hole Size
Y = Minimum Distance
W = Width
Self Clinching Stud
Steel and Stainless Steel
Available in Steel or Stainless Steel
A PDF data sheet available for download
Listing the parts available
L = Length
T = Thread Width
H = Head Diameter
D = Minimum head Clearance
Self Clinching Standoff
Open Ended
Available in Steel or Stainless Steel
A PDF data sheet available for download
Listing the parts available
L = Length
H = Head Diameter
D = Hole Size
T = Thread Size
X = Minimum Clearance
Self Clinching Standoff
Closed End
Available in Steel or Stainless Steel
A PDF data sheet available for download
Listing the parts available
L = Length
H = Head Diameter
D = Hole Size
T = Thread Size
X = Minimum Clearance
CD Weld Studs
External Thread
Available in Stainless Steel, Steel Copper Plated, Aluminium and Brass.
A PDF data sheet available for download
Listing the parts available
D1 = Head Diameter
D2 = Pin Diameter
L = Length
A = Head Thickness
B = Shank
D = Thread Size
L2 = Length When Welded
Rivetstud
Stud
Available in Steel or Stainless Steel.
A PDF data sheet available for download
Listing the parts available
D = Body Diameter
H = Head Diameter
L = Body Length
HT = Head Thickness
T = Thread Size
L1 = Body Size Formed
L2 = Thread Length
Self Tapping Thread Inserts
Hardened Steel, Stainless Steel & Brass
Available in Hardened Steel, Stainless Steel & Brass
A PDF Data sheet is available for download
Listing the parts available
d = Bolt Thread Size
D = Insert Thread Size
L = Length
Type 'U' Hammer Drive Screw
Hardened Steel Electro Brassed Finish
Made of Hardened Steel with an Electro Brassed Finish.
A PDF is available for download
HSS Drill Bits
Rolled High Speed
Rolled high speed, straight shank HSS drill bit. Split point 118 degrees. For drilling steel & plastic
A PDF Data sheet is available to download with size options
L = Overall Length
W = Diameter
